2016 Mobert Delta 110-130 Bottom Seal Machine
From the Bottom Seal collection
SKU: BMBS0100
The Mobert Delta 110-130 Series is a specialized high-speed automatic bag-making machine for producing shoppers and bottom welded bags. This Italian-engineered system features Mobert's patented film block technology that allows instant production changeovers and an exclusive welding group movement system for increased sealing time at high speeds. The Delta 110 (3-track) runs at up to 300 cycles/min with 1100mm maximum bag width, while the Delta 130 (4-track) handles 1300mm widths at 280 cycles/min. Both models process HDPE/LDPE films with speeds up to 150 meters/min and include options like automatic pack forming up to 500 bags.
Key Specifications:
- Maximum Bag Width: 1100mm (Delta 110) / 1300mm (Delta 130)
- Maximum Speed: 300 cycles/min (Delta 110) / 280 cycles/min (Delta 130)
- Film Speed: Up to 150 meters/min on both models
- Film Types: HDPE (min 0.008mm) to LDPE (max 0.060mm)
- Collection System: Packs on pins at 120mm from cutting edge
- Track Configuration: 3-track (Delta 110) / 4-track (Delta 130)
Available Options:
- Automatic folding unit for pack of bags
- Pack former for up to 500 bags
- Block-notes pack device
- Self-centering reel holder
- Melting point system
